MTP®/MPO Trunk Cables

Key Features

100% pre-terminated and tested in factory
Rapid configuration and networking, reduce installation time
Supports 40G and 100G network applications
Jacket material: LSZH, OFNR, OFNP available
Supports up to 12F, 24F, 48F, 72F, 96F, 144F, customizable

Applications

Data center network
Optical system access network
Storage area networking fiber channe
lHigh density architectures

Products Overview

MTP®/MPO Trunk Cables are high-density, pre-terminated fiber optic solutions engineered for fast, reliable, and scalable connectivity in modern data centers, enterprise networks, and high-speed communication infrastructures. Designed to support 40G, 100G, 400G, and beyond, these trunk cables deliver exceptional optical performance with minimal deployment time.
Each trunk cable features factory-terminated, precision-polished MTP® connectors on both ends—available in 12F, 24F, or 48F fiber counts—and is built using premium OM3, OM4, OM5, or SM fiber. The cables are fully compliant with IEC 61754-7 and TIA-604-5 (FOCIS-5) standards and offer polarity options (Type A, B, or C) for flexible system integration.

Connector	Mode	Endface	Standard		Elite
Connector	Mode	Endface	IL (max) dB	RL (min) dB	IL (max) dB	RL (min) dB
MPO/MTP®	SM	12F/APC	≤0.70	≥60	≤0.35	≥60
		24F/APC	≤0.75	≥60	≤0.35	≥60
		48F/APC	≤0.75	≥60
	MM	12F/PC	≤0.50	≥30	≤0.35	≥30
		24F/PC	≤0.50	≥30	≤0.35	≥30
		48F/PC	≤0.50	≥30

Note:

1.Test wavelength: SM@1310/1550nm, MM@850/1300nm;
2.Standard conformance: GR-326, GR-1435.

Mechanical Properties

Item		Criteria	Conformance
ΔIL After 50 Matings	MPO/MTP®	≤0.3dB	GR-1435
ΔIL After 500 Matings	LC/SC/FC/ST	≤0.2dB	IEC 61300-2-2
Min Bend Radius (Dynamic)		20×OD (Cable Diameter)
Min Bend Radius (Static)		15×OD (Cable Diameter)

Environment Condition

Item	Criteria	Conformance
Operation Temperature	-20~70°C	IEC 61753-1
Storage Temperature	-40~85°C
